Battle class rules
This page explains how to configure federation class rules so that the Round Guide automatically generates the correct round skeleton — placing round, battle layers, B‑final — for each competitor count in a 1v1 battle discipline.
Competition operators: see Battle bracket setup for how to seed and run battles once the skeleton exists.
Two approaches
| Approach | When to use |
|---|---|
| Brackets mode (recommended for new classes) | One trigger rule + a few optional modify rules handles every count automatically. Add this to a new class or replace a dense per-count ruleset. |
| Manual per-count rules (legacy / custom) | Fine-grained control, or when an existing ruleset is working and does not need migration. Fully supported; the two approaches cannot be mixed on the same class. |
Brackets mode
Brackets mode replaces the per-count round_sizes + round_type: battle approach with a single trigger rule. The generator builds the complete bracket skeleton — placing, quarter, semi, final, and optionally R16 — for any competitor count automatically.
Trigger rule
Create one class rule with no conditions and no action containing:
[
{ "key": "round_type", "value": "brackets" },
{ "key": "round_sizes", "value": [2, 4, 8, 200] }
]
The round_sizes value doubles as the bracket depth setting. The generator reads the largest finite value (anything below 200) as the maximum bracket entry size:
round_sizes | Max bracket entry | Effect |
|---|---|---|
[2, 4, 8, 200] | 8 | Quarter is the deepest battle level; counts ≥ 16 do not get an R16 round |
[2, 4, 8, 16, 200] | 16 | R16 (Åttondelsfinal) is added when count ≥ 16 |
What gets generated per count
The generator selects the bracket structure based on competitor count and max bracket entry:
| Count | Structure | Battle children |
|---|---|---|
| 2 | Final | 1 |
| 3 | Semi (1 trio, top 2 advance) → Final | 1 + 1 |
| 4–5 | Placing → Semi (2 pairs) → Final | 2 + 1 |
| 6 | Placing → Semi (3 pairs, or 2 trios via modify rule) → Final | 3 or 2 + 1 |
| 7 | Placing → Quarter (4 pairs, one bye) → Semi → Final | 4 + 2 + 1 |
| 8–max | Placing (all through) → Quarter → Semi → Final | 4 + 2 + 1 |
| > max, max=8 | Placing (top 8) → Quarter → Semi → Final | 4 + 2 + 1 |
| ≥ 16, max=16 | Placing → R16 (8 pairs) → Quarter → Semi → Final | 8 + 4 + 2 + 1 |
The Placing round always uses select judging; the Final always uses placement judging. Both are set from the federation’s judging configuration; no per-round judging rule is needed unless you want to override them.
B‑final
B‑final is not auto-generated. Add an explicit add rule on the semifinal position:
| Condition | Action | Changes |
|---|---|---|
round == 2, from end | add | round_label: B-final, round_num_through: 0, round_position: 3, judging: match |
This keeps B‑final optional and lets you control which classes have one.
Crosses / trio mode for count 6
By default, count 6 produces a semi with 3 pairs of 2. To use trios (crosses) instead — two heats of 3, winner of each advancing — add a modify rule:
| Condition | Action | Changes |
|---|---|---|
count == 6, round == 2, from end | modify | judging: select, max_floor: 3 |
With max_floor: 3, the semi generates 2 trio children (3 competitors each, 1 advancing) instead of 3 pair children.
Customising round labels
Set a round_label array on the trigger rule to name the bracket levels. The array maps from Final (index 0) outward:
{ "key": "round_label", "value": ["Final", "Semifinal", "Kvartsfinal", "Åttondelsfinal", "Uttagning"] }
Override a specific round’s label (e.g. the placing round) with a per-round modify rule:
| Condition | Action | Changes |
|---|---|---|
round == 1, from start | modify | round_label: ["Uttagning"] |
Placing round judging and music
Configure the placing round with a condition that excludes very small brackets where there is no placing round:
| Condition | Action | Changes |
|---|---|---|
round == 1, from start, count >= 4 | modify | judging: 10-0, round_label: ["Uttagning"], max_floor: 4, dances |
round == 1, from end | modify | music_length: 240, extra_time: 40 |
Complete example — Solo Champion Vuxna (R16 enabled)
| # | Conditions | Action | Changes |
|---|---|---|---|
| 1 | (none) | modify | round_type: brackets, round_sizes: [2,4,8,16,200], round_label: ["Final","Semifinal","Kvartsfinal","Åttondelsfinal","Uttagning"] |
| 2 | round == 1, from start, count >= 4 | modify | judging: 10-0, round_label: ["Uttagning"], max_floor: 4, dances |
| 3 | round == 2, from end | add | round_label: B-Final, round_num_through: 0, round_position: 3, judging: match |
| 4 | round == 1, from end | modify | music_length: 240, extra_time: 40 |
Result: counts 2–15 get the standard Quarter→Semi→Final bracket; counts ≥ 16 automatically add an R16 layer. All handled by 4 rules instead of 13–17.
Complete example — Solo Champion Barn / FDO (max 8, with crosses)
| # | Conditions | Action | Changes |
|---|---|---|---|
| 1 | (none) | modify | round_type: brackets, round_sizes: [2,4,8,200], round_label: ["Final","Semifinal","Kvartsfinal","Uttagning"] |
| 2 | round == 1, from start, count >= 4 | modify | judging: 10-0, round_label: ["Uttagning"], max_floor: 6 |
| 3 | count == 6, round == 2, from end | modify | judging: select, max_floor: 3 |
| 4 | round == 2, from end | add | round_label: B-Final, round_num_through: 0, round_position: 3, judging: match |
| 5 | round == 1, from end | modify | music_length: 240, extra_time: 40 |
Result: count 6 gets 2 trios (crosses) for the semi; all other counts use standard pairs. No R16 regardless of count.
Manual per-count rules (legacy)
The following sections document the original approach: an explicit round_sizes rule plus round_type: battle modify rules for each competitor count. Use this approach for existing class rule sets that are already working. Both approaches are fully supported; do not mix them on the same class.
How round sizes work
The round_sizes rule sets the bracket ladder for the size loop:
[2, 4, 8, 16, 200]
Given 10 competitors and this ladder, the generator finds the first size at or above 10 (16) and builds downward: Placing(16) → Quarter(8) → Semi(4) → Final(2).
Round sizes can be overridden per count — set round_sizes on a rule with a count condition to use a different ladder for a specific bracket size.
From-end conditions
Rules that should fire at a specific bracket position use a from-end condition: round == N, from end. This is count-agnostic — the Final is always round 1 from end, the Semi is round 2 from end, regardless of total rounds.
Rules that should only fire when a quarter exists combine two conditions:
round == 3, from end ← the quarter layer
round >= 2, from start ← excludes the first round (placing)
Count 2 — direct final
round_sizes: [2]
Single Final. No placing round.
Count 3 — crosses semifinal
round_sizes: [2, 3]
Generates: Placing(3, 2 advancing) → Final(2).
| Condition | Action | Changes |
|---|---|---|
count == 3, round == 1, from start | modify | judging: select, round_label: Semifinal, max_floor: 3, round_num_through: 2 |
Count 4 — semis + B‑final + final
round_sizes: [2, 4, 200]
Generates: Placing(4, all advancing) → Semi(4, 2 advancing) → Final(2).
| Condition | Action | Changes |
|---|---|---|
count == 4, round == 1, from start | modify | judging: 10-0 or select, round_num_through: 4 |
count == 4, round == 2, from end | modify | round_type: battle, judging: match, round_label: Semifinal |
count == 4, round == 1, from end | modify | round_type: battle, judging: match, round_label: Final |
count == 4, round == 2, from end | add | round_label: B-final, round_num_through: 0, judging: match |
Count 5 — 5th eliminated, then 4‑bracket
round_sizes: [2, 4, 200]
Same structure as count 4, but the placing round advances only 4.
| Condition | Action | Changes |
|---|---|---|
count == 5, round == 1, from start | modify | round_num_through: 4 |
Then apply the same battle + B‑final rules as count 4 with count == 5 conditions.
Count 6 — crosses semis + B‑final + final
round_sizes: [2, 6, 200]
Generates: Placing(6, all advancing) → Semi(6, 2 advancing) → Final(2).
| Condition | Action | Changes |
|---|---|---|
count == 6, round == 2, from end | modify | judging: select, round_label: Semifinal, max_floor: 3, round_num_through: 2 |
count == 6, round == 2, from end | add | round_label: B-final, round_num_through: 0, judging: match |
Count 7 — one bye + adjusted bracket
round_sizes: [2, 4, 7, 9]
Generates: Placing(9, all advancing) → Quarter(7) → Semi(4) → Final(2).
| Condition | Action | Changes |
|---|---|---|
count == 7, round == 1, from start | modify | round_num_through: 100%, judging: 10-0 |
count == 7, round == 3, from start | modify | round_type: battle, judging: match, round_label: Quarterfinal |
count == 7, round == 4, from start | modify | round_type: battle, judging: match, round_label: Semifinal |
count == 7, round == 4, from start | add | round_label: B-final, round_num_through: 0, judging: match, round_position: 3 |
Count 8 — standard 8‑bracket
round_sizes: [2, 4, 8, 21]
Generates: Placing(8, all advancing) → Quarter(8) → Semi(4) → Final(2).
| Condition | Action | Changes |
|---|---|---|
count == 8, round == 2, from end | modify | round_type: battle, judging: match, round_label: Quarterfinal |
count >= 8, round == 2, from end | add | round_label: B-final, round_num_through: 0, judging: match, round_position: 3 |
Count 9–20 — standard 4-layer bracket
round_sizes: [2, 4, 8, 21]
| Condition | Action | Changes |
|---|---|---|
count >= 9, count <= 20, round == 1, from start | modify | judging: 10-0, round_label: Placing round |
count >= 9, count <= 20, round == 2, from start | modify | round_type: battle, judging: match, round_label: Quarterfinal |
count >= 9, count <= 20, round == 3, from start | modify | round_type: battle, judging: match, round_label: Semifinal |
count >= 9, count <= 20, round == 3, from start | add | round_label: B-final, round_num_through: 0, judging: match, round_position: 3 |
Count 21 or more — qualification + placing + bracket
round_sizes: [2, 4, 8, 16, 200]
| Condition | Action | Changes |
|---|---|---|
count >= 21, round == 1, from start | modify | judging: select, round_label: Qualification round |
count >= 21, round == 2, from start | modify | judging: 10-0, round_label: Placing round |
count >= 21, round == 3, from start | modify | round_type: battle, judging: match, round_label: Quarterfinal |
count >= 21, round == 4, from start | modify | round_type: battle, judging: match, round_label: Semifinal |
count >= 21, round == 4, from start | add | round_label: B-final, round_num_through: 0, judging: match, round_position: 3 |
The B‑final add rule
Applies to both approaches. The key fields:
| Field | Value | Effect |
|---|---|---|
round_label | B-final | Name shown in the round list |
round_num_through | 0 | Nobody advances from the B‑final |
round_position | 3 | Losers placed 3rd (runner-up position offset) |
judging | match | 1v1 battle judging |
When the add rule fires, the generator creates the B‑final alongside the semi. Setting round_others_id on the semi to point to the B‑final (done automatically when using the Round Guide import) means the Assign teams button routes semi losers to the B‑final without operator action.
Seeding — how it works automatically
When an organiser runs Assign to match on a battle round and picks a source round, the system applies the tournament bracket generator:
- From a non-battle source (placing or qualifying round): seeds by placement rank using the standard fold — Seed 1 vs last, Seed 2 vs second-to-last, etc. For 8 competitors this produces 1v8, 2v7, 3v6, 4v5.
- From a battle source (previous bracket layer): collapses winners from each previous match into new pairings, preserving the bracket structure.
- Byes (size 7): when the fold produces a match with no second competitor, that slot is empty. The single competitor advances automatically.
No configuration is needed for seeding — it is always determined by the source round’s placement results.
Validating your setup
After creating or editing rules, open the Round Guide for a test competition class and try several competitor counts. Confirm:
- The correct number of rounds is generated for each count.
- Battle rounds show children (one per match).
- The B‑final appears alongside the semifinal, not after the final.
- For count 2: only a Final is generated (no placing round).
- For count 3: the semi uses select judging.
- For count 6 with crosses: the semi generates 2 trio children (3 competitors each).
- For count 7: the quarterfinal shows 4 battles, one of which will receive only Seed 1 when seeded.
- For brackets mode with max=16: counts 16+ produce an R16 layer; counts below 16 do not.
